SPECIFICATIONS

• Brand: Yugong
• Product type: Crawler spider crane
• Models: YG03, YG05 and YG08
• Maximum lifting capacity: 3 t / 5 t / 8 t by model
• Maximum lifting height: Up to 18 m
• Maximum working radius: Up to 16.5 m
• Boom length: 4.7–16.5 m; extension time 54 sec
• Boom angle: 0–78°, rotation cycle 13 sec
• Hook rising speed: Up to 18 m/min
• Wire rope: 11 mm × 80 m for YG05/YG08
• Drive: Hydraulic motor
• Walking speed: 0–2.5 km/h
• Gradeability: 25° / 36%
• Dimensions: 5 × 1.6 × 2.18 m
• Core components: PLC, engine, bearing, pressure vessel, gear and pump
• Condition: New
• Certification: CE
• Warranty: 2 years
