SPECIFICATIONS

Brand: YG

Model: CPZM20D

Type: Mobile concrete pump

Working capacity: 15–20 m³/h

Power: 30 kW motor

Power type: Changchai

Outlet pressure: 10 MPa

Distribution valve: S-pipe valve

Conveying cylinder size: 140 × 650 mm

Discharge port diameter: 100 mm

Maximum aggregate diameter: 30 mm

Maximum horizontal conveying distance: 250 m for aggregate below 20 mm; 80 m for 20–30 mm

Maximum vertical conveying distance: 120 m for aggregate below 20 mm; 50 m for 20–30 mm

Dimensions: 3,400 × 1,100 × 1,700 mm

Weight: 1,100 kg

Warranty: 1 year

Machinery test report: Provided
